Dimension
- Total area: 7.45 m wide x 18 m deep
- Telescopic bleachers: 7.20 m wide x 7.60 m deep
- Performance area: 6.5 m wide x 5 m deep
- Portable stage (for standing room setup): 7 m wide x 5 m deep x 0.8 m high
BLACKBOX
The possibilities in the BLACKBOX are endless. From jazzy club concerts, literary events, and try-outs, to mini-festivals.
The BLACKBOX is a flat floor hall with telescopic bleachers and exclusively blackbox masking. The hall is located at street level.
Capacity
- Seated: 91 people
- Standing: 160-180 people (depending on size of stage)
Grid
Rectangle of black Prolyte H30V square truss
- Dimensions: 6.6 m wide x 7.5 m deep
- 5 trusses distributed across
- Maximum height at bottom of truss: 5.20 m
- Maximum distributed load: 2000 kg
- Maximum point load: 80 kg
- The grid is suspended by 6 electrically controlled motors and can be lowered as a whole to working height.
3x individually controllable Prolyte XU30D triangular truss
- Dimension: 6.60 m wide
- 1 at the back and 2 above the bleachers
Electricity
Upstage right
- 1x CEE32A
- 1x CEE63A
- 1x CEE125A
Light
- 72x 2,5 kW dimmer channels
Sound
- 2x d&b audiotechnik Q-Sub per side
- 1x d&b audiotechnik Q-7 per side
